Ci-RX6100 UHF Android Portable Reader
RFID Reader
UHF
Handheld RFID Reader
Asset Management
4G
Android OS
NFC RFID
Ci-RX6100 is the newly released UHF RFID android handheld reader with sensitivity Impinj RFID chip, reading range up to 20m in open area. It is equipped with android 10 operation system, 5.5” rugged touch screen with high resolution, is available for 1D/2D barcode scanner(optional) and multi-protocol (HF/NFC optional) standards, shall match high standards in logistics tracking, warehouse inventory checking, smart retailing solutions etc.
CPU:Cortex-A73 2.0GHz octa-core
Operation system:Android 10.0
Memory:2GB RAM / 16GB ROM; or 4GB RAM / 64GB ROM; Support max 256GB Micro SD card
Touchscreen:5.5 inch Gorilla Glass TFT-LCD with backlight, resolution 720 * 1440
Expansions (optional):1 SIM card slot, 1 PSAM card slot, 1 TF card slot
Communication port:Type-C
GPS:Build-in A-GPS, accuracy ±5m
Color Camera:Rear 13 megapixel, front 5.0 megapixel, auto focus with LED flash
WWLA:TDD-LTE Band 38, 39, 40, 41; FDD-LTE Band 1, 2, 3, 4, 7, 17, 20; WCDMA (850 / 1900 / 2100MHz); GSM / GPRS / Edge (850 / 900 / 1800 / 1900MHz)
WLAN (WIFI):2.4G / 5G dual frequency, support IEEE802.11a /b /g /n /ac
Bluetooth:Bluetooth Class v2.1+EDR, Bluetooth v3.0+HS, Bluetooth v4.2
2D CMOS Imager:Zebra SE4710 / Mindeo ME5600
Symbologies:PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode, Postal Codes, US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal, Dutch Postal etc
Working frequency:865-868MHz or 902-928MHz
Protocol:EPC Class1 GEN2 / ISO18000-6C
Antenna gain:4dBi circular polarization build-external
Reading distance:16-20m (tag type matters)
Working frequency:13.56Mhz
Protocol:ISO15693 & ISO1443A
Reading distance:2-5cm
Protocol:ISO7816
Baudrate:9600, 19200, 38400, 43000, 56000, 57600, 115200
Slot:2 slots(maximum)
Weight:600g (including battery & pistol)
Dimension:166 * 79 * 31±2mm (pistol excluded)
Battery:Rechargeable li-ion polymer, 3.8V, 9000mAh
IP rating:IP65, IEC compliance, withstand 1.5m drop
Working Temperature:-20°C ~ 50°C
Storage Temperature:-40°C ~ 70°C
Standard Accessary:Lithium battery, Power adaptor, type-C data cable
Optional:Cradle
