Ci-RT209 LED and Buzzer Active Tag
RFID Tag
2.4Ghz
Long Range RFID
Long Battery Life
LED tag
accsts tracking
asset location
Ci-RT209 LED & Buzzer tag works in 2.45GHz frequency band in passive working mode, reading distance can reach 100m with 2.4Ghz active readers. The tag has both LED and buzzer for searching purpose, the bright LED and loud buzzer make tag easy to find in complex environment, meanwhile it has confirming button to close LED and buzzer when tag is found. It is very suitable for application such as asset management/ monitoring/ locating etc.
Working frequency:ISM 2.4-2.48GHz
Modulation:GFSK
RF power:-16 ~ +0dBm( default 0dBm)
Tag ID:4 byte
Working mode:Passive operating mode (response only receive signal from reader)
Memory:512 bytes
Battery life time:4-year (related with tag output power and LED/Buzzer working frequency)
Battery low alarm:Yes
Reading distance:5-100 m
Dimension:96.3* 40* 16mm
Weight:35g
Status indication:Bright LED, buzzer, confirm button
Material:ABS + PC
Working temperature:-20°C~ +60°C
Storage temperature:-25°C~ +70°C
Humidity:5% ~ 95%
IP rating:IP64
