Ci-RI943 8dBi Rugged Integrated UHF RFID Reader
RFID Reader
UHF
Middle Range RFID
Circular Polarization
RFID Access Control
RFID Vehicle Management
Inventory Tracking
GPIO
Ci-RI943 Integrated Rugged UHF RFID reader provides high performance uhf RFID Reading in tough and rugged environment, it’s based on high performance Impinj RFID chip, small in size but big in reading distance. The reader is highly resistant to water and dust, IP66 rating suitable for tough environment.
Applications
Asset & LogisticsPersonnel ManagementWarehouse ManagementProduction Line ManagementWaste ManagementAuto Weighting SystemWarehouse RFID Forklift SystemRFID Parking Access Control SystemRFID Asset ManagementRFID Laundry ManagementRFID Textile ManagementRFID Time Attendance SystemRFID Tracking System For InmateRFID System for Construction Site SafetyRFID for Miners Management
Operating Frequency:866-868Mhz EU, 902-928Mhz FCC, 920-925Mhz China, Other frequency band customizable
Working Protocol:EPC C1 GEN2 (ISO18000-6C)
Working mode:FHSS/Fixed frequency
RF Output Power:15dBm ~ 33dBm (@1dBm per step)
Antenna gain:8dBi, circular polarization
Communication interface:RJ45 (Ethernet), RS232, RS485, Wiegand26/34)
GPIO:2 channel relay output, 1 channel photoelectric isolation input
Reading distance:0 ~ 12m (depends on antenna and tag as well)
Writing distance:0 ~ 3m
Working Voltage:DC 12V/3A
Dimensions:228* 228* 66mm
Weight:1.5 kg
Material:ABS
Operating Temperature:-40°C ~ +70°C
Storage Temperature:-40°C ~ +85°C
Humidity:5% ~ 95% (non-condensing)
Waterproof:IP66
