Ci-RF946 Four-port Fixed UHF RFID Reader

RFID Reader
UHF
Middle Range RFID
Waterproof
GPIO
Asset Management
Harsh Environment
High Protecting
Ci-RF946 is an industrial four-port UHF RFID Reader, compatible with EPC C1 GEN2 protocol RFID tags, support dense read mode(DRM), super anti-collision function, IP 67 protection rating with industrial degree, idea for harsh environment application.
Applications
Smart CityAsset & LogisticsPersonnel ManagementWarehouse ManagementProduction Line ManagementWaste ManagementAuto Weighting SystemWarehouse RFID Forklift SystemRFID Parking Access Control SystemRFID Asset ManagementRFID Laundry ManagementRFID System for Construction Site Safety
  • UHF frequency band, support 866-868Mhz CE, 902-928Mhz FCC, other frequency band customizable
  • Industrial design, red dot design award, IP67 protection rating
  • One-piece die-casting, excellent heat dissipation, reliable performance
  • 4-TNC RF connectors
  • Self-developed R2000 chip module, reading range 20m adjustable
  • Support RJ45, RS232/RS485, GPIO
  • Production line management
  • Asset tracking
  • Warehouse management
  • Container management
Operating Frequency:866-868Mhz EU, 902-928Mhz FCC, 920-925Mhz China, Other frequency band customizable
Protocol:ISO18000-6C (EPC Class1 Gen2)
Working mode:FHSS/Fixed frequency
Antenna port:4 TNC connector
RF output:10dBm~33dBm (@1dBm per step)
Reading range:0~20m (depends on antenna and tag type)
Writing range:0~3m (depends on antenna and tag type)
Reading speed:300pcs/s
Communication Port:RJ45 (Ethernet), RS232/RS485
IO Port:2 channel relay output, 1channel photoelectric isolation input
Power supply:DC 12V/3A
Material:Aluminum alloy
Dimension:186 *186 *34mm
Weight:865g
Working temperature:-20℃~ 65℃
Storage temperature:-30℃~ 75℃
Humidity:5%~95% (non-condensing)
Waterproof:IP67
