Ci-RF231 Omni-directional Active Reader
RFID Reader
Active RFID Reader
2.4Ghz
Omni Directional RFID
Long Range RFID
Distance Measurement
Desktop Reader
SDK-API
GPIO
Asset Management
Ci-RF231 is omni-directional reader with the wide reading range and high reading speed, feature with more than 100m reading radius, high reliablity suitable for tunnel personnel tracking, industrial data acquistion, asset monitoring and tracking etc.
Working Frequency:ISM 2.4-2.48GHz
Output Power:Max +15dBm, step -2dB, software adjustable
Receive sensitivity:-93dBm
Antenna port:1 SMA connector
Antenna gain:Default 6dBi omni-directional, other type optional
Data ports:RS232, Ethernet
Data ports(optional):RS485, Wiegand 26/34 (customizable)
GPIO:2 channel trigger (optical isolated) input (5V, <20mA); 2 channel relay output (30V, <1000mA)
Firmware upgrade:Support RS 232 connection updating with specified software
Application software:API in C++/C#
Tag protocol:Private
Reading distance:0-150m radius (antenna/tag type matter)
Reading speed:300pcs/s
Dimensions:168 *145 *42.5mm (antenna excluded)
Weight:500g
Power Supply:DV 5V/2A
Power consumption:200mw standby, 400mw working
Working Temperature:-30°C~+70°C
Storage Temperature:-40°C~+80°C
Working Humidity:5% ~ 95% (non-condensing)
IP Rating:IP 55
Installation:Ceiling or desktop
