Ci-F286 2.4Ghz Android Active RFID Fixed Reader
RFID Reader
Active RFID Reader
2.4Ghz
4G
Long Range RFID
Integrated RFID
RFID Access Control
SDK-API
GPIO
Waterproof
Ci-F286 is newly invented active RFID reader build-in android platform with high performance, it is fixed RFID reader with more than 180m reading distance in open area, the build-in android os adapts reader for any application requirement. The reader is highly resistant to water and dust, IP66 rating suitable for tough environment.
Working frequency:ISM 2.4-2.48GHz
RF Output Power:Max +15dBm,step -2dB, software adjustable
Receive sensitivity:-93dBm
Antenna:Build-in 12dBi antenna
Firmware upgrade:Support TCP upgrading
Application software:API in C++/C#, android
Tag protocol:Private
Reading distance:0-180m radius (antenna / tag type matters)
Reading speed:300 pcs/s
Dimension:228* 228* 66mm
Weight:1.8 kg
Power Supply:DV 12V/3A
Working Temperature:-30°C ~ +70°C
Storage Temperature:-40°C ~ +80°C
Humidity:5%~95%( non-condensing)
IP Rating:IP66
Installation:Pole mounting
Communication ports:RS232, Ethernet
Communication ports(optional):RS485, Wiegand 26/34 (customizable)
Wireless function:WIFI, 4G (optional)
GPIO:2 channel trigger (optical isolated) input (5V, <20mA); 2 channel relay output (30V, <1000mA)
